Automatic Aluminum Corner Connector Cutting Saw

Automatic Aluminum Corner Connector Cutting Saw

Automatic Aluminum Corner Connector Cutting Saw

Automatic aluminum corner connector cutting saw machine, suitable for cutting aluminum window and door corner connectors. Features PLC automatic feeding and counting, imported saw blades, precise and efficient operation, and is ideal for mass production.
share：

Automatic Aluminum Corner Connector Cutting Saw

Automatic aluminum corner connector cutting saw machine, suitable for cutting aluminum window and door corner connectors. Features PLC automatic feeding and counting, imported saw blades, precise and efficient operation, and is ideal for mass production.
share：
Technical Specifications
Parameter Specification Parameter Specification
Power Voltage 380V/50Hz Input Power 2.2 kW
Working Air Pressure 0.5-0.8 MPa Air Consumption 120 L/Min
Motor Speed 2,840 rpm Saw Blade Feed Speed 0-3 m/Min
Automatic Feeding Length 3-400 mm Cutting Height 120 mm
Saw Blade Diameter Φ450 mm
Overall Dimensions 1250 × 950 × 1250 mm
Equipment Performance
  • This machine is mainly used for cutting aluminum door/window corner brace profiles.
  • Automatic feeding is controlled by PLC, ensuring stable and efficient operation suitable for mass production.
  • Equipped with an automatic counting system that records the number of cuts, facilitating batch processing.
  • Uses imported carbide saw blades, providing high processing accuracy and long durability.
  • The machine features simple operation, reliable performance, advanced technology, and easy maintenance.
