Single-Head Hydraulic Punching Machines
The single-head hydraulic punching machines features a stable hydraulic system for reliable operation. It can punch V-notches and hardware installation holes with adjustable mold height, cutting width, and depth, ensuring simple operation and high efficiency.
share：
I. Technical Specifications
| Item | Specification | Item | Specification |
| Rated Input Voltage/Frequency | 380V/50Hz | Total Power | 1.5KW |
| Rotational Speed | 1400r/min | Air Consumption | 30L/min |
| Rated Pressure | 5 MPa | Nominal Pressure | 30KN |
| Punch Stroke | 30MM | Weight | Approx. 160kg |
| Overall Dimensions | 1000×1200×1700mm | ||
II. Equipment Performance
- This machine adopts a hydraulic power system for control, ensuring stable and reliable operation.
- Utilizing a punching and shearing mechanical principle, it can punch V-shaped notches and installation holes for hardware components such as handles and locks.
- The mold opening height is controlled by limit switches on the machine panel. The lower limit switch controls the mold closing height, while the upper proximity switch controls the mold opening height. Stroke height adjustment is achieved via M8 bolts on the panel, offering simple operation and high work efficiency.
- The lower blade of the steel lining mold features adjustable blocks on both sides for shearing width adjustment. The shearing depth of the steel lining can be adjusted by positioning blocks.
