This CNC saw & milling integrated workstation features a five-channel control system, laser cutting unit, and intelligent robotic arm for efficient multi-process aluminum profile machining. It supports arbitrary-angle cutting and independent corner guard processing for flexible and high-efficiency production.
share：
Super CNC Saw & Milling Integrated Workstation
This CNC saw & milling integrated workstation features a five-channel control system, laser cutting unit, and intelligent robotic arm for efficient multi-process aluminum profile machining. It supports arbitrary-angle cutting and independent corner guard processing for flexible and high-efficiency production.
share：
I. Equipment Advantages
Channel 1 · Laser Independent Track
Channel 2 · Front Spindle Independent Station
Channel 3 · Rear Lower Spindle Independent Station
Channel 4 · Upper Spindle Independent Station
Channel 5 · Upper Saw Arbitrary Angle Cutting
- Newly equipped with the ultimate “Central Brain” (HAN’s System Five Channels) that integrates overall operations, delivering a smarter experience!
- Independent Five Channels—Separate processing zones avoid interference and enable more efficient collaborative work!
- Track-type Laser Cutting Device—Longer travel, enabling corner hole and glue hole processing without time loss!
- Intelligent Robotic Arm—Automatic error correction, material clamping sensing, automatic rotation, and smart memory!
- Upper Saw Blade Arbitrary Angle Cutting—Capable of cutting any angle and corner guards to meet diverse processing needs!
- Independent Corner Guard Cutting Device—Equipped with an independent tail blade corner guard cutting device, offering more than just speed!
II. Main Technical Parameters
| Item | Specifications |
| Overall Dimensions (L × W × H) | 17500 × 3500 × 2500 mm (excluding chip conveyor dimensions) |
| Chip Conveyor Dimensions (L × W × H) | Approx. 3150 × 500 × 700 mm |
| Total Weight | Approx. 11.5 tons |
| Input Power | 380V / 50Hz, three-phase four-wire system |
| Working Air Pressure | 1.6 MPa |
| Sawing Speed | 15–50 m/min |
| Servo Operating Speed | 40–130 m/min |
| Blank Material Length | 1100 ≤ L ≤ 7000 mm |
| Sawing Length | ≥ 300 mm |
| Loading Table Capacity | 8 + 1 pieces cyclic loading |
| Saw Blade Diameter | Φ550 mm |
| Sawing Angles | 45°, -45°, 90°, |
| Sawing Method | Lower 45° output, upper saw blade |
| Profile Processing Range | Height: 130 mm; Width: 130 mm |
| Drilling Methods | One rear output, one upper output, one lower output, one front output (swivel angle) |
| Laser Processing Methods | Rear laser cutting + marking, front laser marking |
