Five-Axis CNC End Milling Machine

This five-axis CNC end milling machine is suitable for end face processing of aluminum profiles. It features dual 3KW spindles and a high-precision configuration. The right machine head is rotatable, allowing for one-time forming. An optional Han's Laser intelligent control system supports barcode scanning for processing, ensuring high efficiency and precision.
share：

Five-Axis CNC End Milling Machine

This five-axis CNC end milling machine is suitable for end face processing of aluminum profiles. It features dual 3KW spindles and a high-precision configuration. The right machine head is rotatable, allowing for one-time forming. An optional Han's Laser intelligent control system supports barcode scanning for processing, ensuring high efficiency and precision.
share：
Technical Specifications
Parameter Specification Parameter Specification
Power Voltage 380V/50Hz Input Power 2 × 3 kW + 3.75 kW
Working Air Pressure 0.5-0.8 MPa Travel Length (X/Y/Z Axis) 1400 / 150 / 200 mm
Motor Speed 3000 rpm Running Speed (X/Y/Z Axis) 0-60 / 0-15 / 0-15 m/min
Processing Range 190 × 60 × 500 mm Milling Cutter Diameter 300 mm
Overall Dimensions 2600 × 1500 (W) × 2000 (H) mm (excluding material support rack)
Equipment Performance
  • This machine is suitable for various face milling operations on aluminum profiles.
  • High-precision linear guide rail pairs, ball screws, gear racks, and servo motors ensure smooth motion and high positioning/machining accuracy.
  • Equipped with dual 3 kW high-speed motor spindles, providing stable rotation, low noise, and strong cutting capability.
  • The right spindle head features a tiltable design for easier cutting, enabling one-time forming after material placement.

The optional Han’s Smart Control system can be integrated with optimization software to support scanning-code processing, making operation convenient and fast, and enhancing production adaptability.
